Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch

Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch
Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch

Großes Bild :  Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch

Produktdetails:
Herkunftsort: Taiwan
Markenname: innolux
Zertifizierung: Rohs,CE,FCC
Modellnummer: M280DGJ-L30
Zahlung und Versand AGB:
Min Bestellmenge: 10PCS
Preis: Negotiation
Verpackung Informationen: Industrielle Verpackung
Lieferzeit: 4-5 Arbeitstag
Zahlungsbedingungen: T/T, W, Western Union, MoneyGram
Versorgungsmaterial-Fähigkeit: 3000pcs pro Woche

Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch

Beschreibung
Qualität: Nagelneue Vorlage Paket: Ursprüngliche industrielle Verpackung
Material: Glas oled Farbe: 16.7M Farben
Modell: WLED Art: Breitbildhohe auflösung 3840*2160
Helligkeit: 300cd Verbindungsstück: 30PIN
Kontrast-Verhältnis: 1600:1 Berufsleben: Stunden 30k
Markieren:

Laptop 3840*2160 Lcd-Monitor

,

Laptop Innolux 28Inch Lcd-Monitor

,

M280DGJ-L30

3840*2160 Pixels innolux 28Inch laptop lcd monitor M280DGJ-L30 300 cd/m² (Typ.) 1000:1 51pin 12V 30k hours WLED



Innolux Corporation (hereafter called Innolux) M280DGJ-L30 is a 28.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by Einklcd in the following: WLED Backlight, Reverse I/F, 10 bit, Matte, G-Sync / FreeSync , Energy Star 7.0 Compliance, Gsync/Freesync. Based on its features, einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q3, 2013, Now this model is in production.  We inputted this model's specification on Aug 15 2013 for the first time, and the latest update on Jul 7 2020. If you want to embed M280DGJ-L30 LCM in your future product,einklcd strongly recommend that you should contact with Innolux or it's distributor to learn lateast production and specification detail. The M280DGJ-L30 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.





Brand
Diagonal Size
Pixel Format
Active Area
Bezel Area
Luminance
View Direction
Viewing Angle
Support Color
Weight
Frame Rate
Innolux
28.0 inch
3840(RGB)×2160 [UHD] 157PPI
620.93(H)×341.28(V) mm
626.93(H)×347.28(V) mm
300 cd/m² (Typ.)
6 o'clock
85/85/80/80 (Typ.)(CR≥10)
1.07B 72% NTSC
2.91/3.10Kgs (Typ./Max.)
60Hz
Model
Type
Configuration
Outline Dim.
Treatment
Contrast Ratio
Response Time
Operating Mode
Light Source
Designed For
Touch Panel
M280DGJ-L30
a-Si TFT-LCD , LCM
RGB Vertical Stripe
648.9(H)×369.3(V) ×20.85(D) mm
Antiglare (Haze 25%), Hard coating (3H)
1000:1 (Typ.) (TM)
1.5/3.5 (Typ.)(Tr/Td)
TN, Normally White, Transmissive
WLED [4 strings] , 30K hours , W/O Driver
Without
Interface Type V-by-One 8 lane 51 pins Connector
Power Supply 12.0V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C





Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch 0Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch 1Lcd-Monitor M280DGJ-L30 300cd/M2 Laptop 3840*2160 Innolux 28Inch 2
